Product Description

General Electric
GE

Name: REBUILT General Electric DC Motor CD506AT 125 HP 500 V 1150/2000 RPM SPFG-SV GE (PM2741-1)
Brand: General Electric
SKU: PM2741
Price: 6914.88 USD
Availability: InStock

MPN: 5CD223PA032A012
REFURBISHED
125HP Paper Mill Duty D.C. Motor
Frame Number: CD506AT

This DC Motor was never put back into service after being fully rebuilt by Prime Electric Motors, Inc. We have all supporting rebuild documentation from Prime Electric Motors, Inc on file (visit link under the "Condition Report").

GE Motors Direct Current Motor
Model: 5CD223PA032A012 - Serial: BT-1-446 BT
Type: CD 506AT - Encl: SPFG-SV - Instr: GEH3967
HP: 125 - RPM: 1150 / 2000 - Volts: 500
Arm Amps: 199 - Wound: Stab Shunt
Fld Amps: 4.82 / 2.0 - Fld Ohms 25C: 45
Insul Class: F - Duty: Cont - Max Ambient: 40 Deg C
Pwr Sup Code: C - FLD V 300 / 150 - SEP Vent 590 CFM at .60 In of H2O
Buyers' Guide: gepowerconversion.com/sites/gepc/files/product/DC_Buyers_Guide_Complete_Guide2012.pdf

Condition Report:
dropbox.com/s/vnoj9c4b6ips861/R65550%20Condition%20Report.pdf?dl=0
Shipping within 1 business day
30 Day Warranty on all purchases

Your purchase will include what is pictured and described above ONLY.
For more info or pictures, please visit our FAQs or contact us :
423 821-4712 - Sales@RiverCityIndustrial.com

For more info on the meaning on motor frame size numbers,please see the following link:Link

For a conversion chart of 3PH amperage to horsepower,please see the following chart:Link

Additional Information

SKU:: PM2741
UPC:: 086156114914
Condition:: Refurbished
Availability:: Ships within 0-1 business days of full payment. Expedited shipping available.
MPN:: 5CD223PA032A012
SKU:: PM2741
Horsepower:: 125 HP
Listed:: 8/1/2017
Approx Shipping Dims (LxWxH):: 40.000" x 26.000" x 48.000"
Approx Shipping Weight:: 2600.0000
Location:: B 70A
UPC:: 086156114914
eBay Listing:: 376906331008

REBUILT General Electric DC Motor CD506AT 125 HP 500 V 1150/2000 RPM SPFG-SV GE (PM2741-1)
